Series	Features	Description	Part No.	Application
GR	Thick Film High Ohm Chip Resistor	Size:0402~1206 Resistance:11MΩ~1MΩ Tolerance: ±1% ±5%	GR Series	Application Guide
HV	Thick Film High Voltage Chip Resistor	Size:0603~2512 Resistance:47Ω~51MΩ Tolerance: ±0.5% ±1% ±2% ±5%	HV Series	Application Guide
TR	Triple Power Chip Resistor	Size:0603~2512 Resistance: 1Ω~1MΩ Tolerance: ±1% ±5%	TR Series	Application Guide
RCP	Thick Film High Power Lead Free Chip Resistors (Pb≤100)	Size:0402~1206 Resistance: 0Ω, 1Ω~10MΩ Tolerance: ±1% ±5%	RCP Series	Application Guide
REFP	Enhanced Film Power MELF Resistor	Operating Temperature Range:-55~ +55 °C; Resistance:0.51Ω~10MΩ Tolerance: ±0.5%~±5% Wattage:1/2W~5W Size:REFP204~REFP501	REFP	Application Guide
RISC	Ignition Noise Suppression Resistor (Ceramic Film Composite Type)	Operating Temperature Range:-55~ +200 °C; Resistance:1KΩ~10KΩ Tolerance: ±5%~±20% Wattage:1/2W~3W Size:RISC20K~RISC50K1	RISC	Application Guide
RHFT	High Frequency Terminator Resistor	Operating Temperature Range:-55 ~ +125 °C; Resistance24.9Ω~75Ω Tolerance: ±0.1%~±1% Wattage:1/64W~2W Size:RHFT204~RHFT201	RHFT	Application Guide
RHVM	High Voltage MELF Resistor	Operating Temperature Range:-55~ +55 °C; Resistance:56Ω~68MΩ Tolerance: ±1%~±5% Wattage:1/6W~3W Size:RHVM16~RHVM300	RHVM	Application Guide
RC100	Composite Film-Type Ceramic Composition MELF Resistor	Operating Temperature Range:-55 ~ +200 °C; Resistance:33Ω~22KΩ Tolerance: ±5%, ±10%,±20% Wattage:1W Size:RC100		Application Guide
UR	Thin Film Precision chip resistors(TCR:25ppm)	Size:0201~2512 Resistance: 1Ω~3MΩ Tolerance: ±1.0%, ±0.5%, ±0.25%, ±0.1%, ±0.05%,±0.02%, ±0.01%	UR	Application Guide
ARU	High Precision Power Thin Film Chip Resistors(TCR:25ppm)	Size:0201~2512 Resistance: 1Ω~3MΩ Tolerance: ±1.0%, ±0.5%, ±0.25%, ±0.1%, ±0.05%,±0.02%, ±0.01%		Application Guide
ART	Thin Film Precision chip resistors(TCR:50ppm)	Size:0201~2512 Resistance: 1Ω~3MΩ Tolerance: ±1.0%, ±0.5%, ±0.25%, ±0.1%, ±0.05%,±0.02%, ±0.01%		Application Guide

Previous 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 Next

Dongguan Aillen Electronic Technology Co., LTD is a capacitor，resistor，inductors manufacturer. famous joint venture manufacturing enterprise for electronic components since 1995 in China. We have four manufacture bases locate in Guangdong.

Q：How does your factory do regarding quality control?

A: Quality is priority. We always attach great importance to quality control from the very beginning to the end:

1) Skillful workers pay great attention to each details in handling the producing and packing processes;

2) We have a professional QA/QC team to ensure the quality.

Q：What is your lead time?

A：Stock: 5-15 days in general. No stock: 30-60 days after samples confirmed. or please contact us by email for specific lead time

base on your order quantities.

Q：What are your terms of delivery?

A: We can accept EXW, FOB, FCA, etc. You can choose one which is the most convenient for you.
